Victorian Railways A2 Class (Walschaerts) | |||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| |||||||||||||||||||||||||||||||||||
| |||||||||||||||||||||||||||||||||||
| |||||||||||||||||||||||||||||||||||
|
The A2 class was an express passenger locomotive that ran on Victorian Railways from 1907 to 1963. A highly successful design entirely the work of Victorian Railways' own design office, its long service life was repeatedly extended as the Great Depression and later World War II delayed the introduction of more modern and powerful replacement locomotives.
History
The introduction of the A2 class marked a turning point in Victorian Railways locomotive design, as it was entirely designed by VR engineers of the newly established Locomotive Design Section and the entire class built in-house at Victorian Railways workshops.[1]
Production
Based on the success[2] of the prototype A2572, a total of 125 Stephenson valve gear A2 locomotives were built between 1907 and 1915. The design was then altered to incorporate larger diameter cylinders, a higher pressure boiler and Walschaerts valve gear, and a further 60 locomotives of that design were produced between 1915 and 1922.[1]
Regular service
For over forty years, the A2was the main express passenger locomotive on the VR, hauling intrastate and interstate services. With a maximum permitted speed of 70 miles per hour (115 km/h),[3] the A2was instrumental in the acceleration of timetables on many lines in the years following its introduction. A2 locomotives famously ran the Geelong Flier,[4] the first named train in Victoria,[5] slashing journey times between Melbourne and Geelong from 90 minutes[6] to 63[7] and, finally, 55 minutes,[8] a time not significantly improved upon until the introduction of 160 km/h Regional Fast Rail services in 2006.[9]
A2s were also used to haul a number of special services, such as the Royal Trains for Australian tours of Prince of Wales and the Duke of York, in 1920[10] and 1927 respectively. Towards the end of their lives, A2995 and 996 also had the distinction of hauling the last broad gauge Spirit of Progress service into Melbourne on 16 April 1962.[11]
With their comparatively high tractive effort (the Walschaerts A2 had a higher nominal tractive effort than any other VR locomotive, regardless of type, until the introduction of the C class 2-8-0 of 1918), they also saw widespread use as a fast goods locomotive, particularly later in their life.[1] As early as the 1920s, it was reported as normal practice that A2 class locomotives requiring adjustment to axle boxes and other moving parts be swapped from passenger to lower-speed freight service to extract more work from them between overhauls.[12]
In 1933, two A2 class locomotives set a haulage record for Victorian Railways when they headed a 75-truck 1,598-long-ton (1,624 t) wheat train from Benalla to Seymour.[13]
Although initially limited to principal mainlines, due to their comparatively heavy axle load, gradual upgrades to secondary lines saw the route-availability of the class expand, together with the range of services they hauled.[14]
In 1928, the A2 was replaced on the principal North East line Sydney Limited and Albury Express services by the considerably more powerful three-cylinder S class Pacifics. However, new locomotive development ground to a halt during the 1930s,[15] with the Great Depression severely affecting both VR traffic volumes and operating revenues, so the A2 continued to be the main express passenger power on all other VR mainlines.
Design Improvements
The majority of A2 locomotives were originally built with saturated steam boilers. The class were gradually fitted with superheaters, and to differentiate between the two variants the saturated steam locomotives were renumbered as A1 class, each being reclassified as A2 class again when fitted with a superheater. Many engines were renumbered two or three times as the railways' management attempted to keep the two subclasses in different number blocks, and as the boundaries between the blocks shifted through the superheating program. The last of the A1 class, No. 808, was converted in October 1949.
Experiments were conducted in 1923–4 with A2 800 using Pulverised Brown Coal (PBC) burning equipment, but the experiment was discontinued and the locomotive returned to black coal operation.[16]
The A2 class, along with other post-1900 VR steam locomotive designs, was equipped with electric lighting from 1926 onwards. Automatic Staff Exchange equipment to allow non-stop high-speed running between track sections was also fitted from 1926 onwards.[17]
Modified front end
In 1933, C class heavy goods locomotive C 5 was equipped with a new front end, based on the Association of American Railroads (AAR) design of self-cleaning smokebox, to improve steaming qualities. The results were very promising, and in 1934 A2998 was selected for a series of further tests aimed at further front end improvement, conducted under the direction of VR Rolling Stock branch engineer, Edgar Brownbill.[18]
Experiments were conducted, based on the work of Dr Wagner of the Deutsche Reichsbahn and E. C. Young of the University of Illinois, with final modifications to the A2 locomotive including:[18]
- Revision of exhaust nozzle and chimney position and diameter, using Wagner's recommended ratios, with a larger 23 in (580 mm) diameter funnel, and a 6 in (150 mm) diameter low exhaust nozzle replacing the original 18+1⁄2 in (470 mm) diameter narrow-flanged chimney and 5+1⁄2 in (140 mm) diameter high exhaust nozzle
- Revision to the firebox grate, using a "rosebud" type grate with reduced air openings to improve fire stability under heavy load and give better firing qualities
- Replacement of full-length 1+3⁄8 in (35 mm) return bend superheater elements with 8 ft 6 in (2.59 m)-long 1+1⁄2 in (38 mm) elements
The sum result of the changes was a significant improvement in power and available tractive effort. Maximum drawbar horsepower increased about 40%, from 860 hp (640 kW) at 26 mph (42 km/h) to 1,230 hp (920 kW) at 32 mph (51 km/h).[18] The improvement was such that the VR was able to further accelerate services hauled by the A2, with the running time of the Melbourne to Bendigo express on the steeply graded 100+3⁄4 mi (162.1 km) line being cut from 162 to 145 minutes, and literally hours being cut from the schedule of the Melbourne to Adelaide Overland express.[19]
The Modified Front End, which cost just £140 ($280) per locomotive at that time, was an extremely cost-effective improvement, and allowed the VR to defer new locomotive construction. The modification was so successful that not only was the entire A2 fleet converted during 1936–39, but also the C, K, N, S and X class locomotive fleets, and its principles were also incorporated into the design of all subsequent steam locomotives built for VR.[18][20]
Other changes
In 1935 an experimental A.C.F.I. (Accessoires pour les Chemins de Fer et l'Industrie) feedwater heater was fitted to A2973. However, there was not sufficient improvement in efficiency for the equipment to be fitted to other locomotives and it was removed twelve years later.[14]
With the reduced exhaust blast resulting from the revised smokebox, smoke deflectors were fitted to prevent drifting smoke from obscuring visibility.[21]
In the years following World War II, problems with the quality and availability of coal supplies caused VR to order the conversion of all 60 Walschaerts A2s to oil firing; in practice, only 56 were altered as four were scrapped before the conversion could be completed.[1]
Late in their life, some of the A2s also received Boxpok driving wheels[14] as their conventional spoked wheels began to suffer fatigue cracks with age and mileage.[22]
Later years
In 1939, by which time most of the class was already over twenty-five years old, World War II broke out. The massive increase in traffic on the VR the war effort brought saw these ageing locomotives subjected to a punishing regime of heavy utilisation and minimal maintenance.[15]
With VR's locomotive workshops switched to production of armaments and all available manpower given to the war effort, plans to eliminate the double-headed A2 operations on Melbourne–Adelaide passenger services with the introduction of more powerful H class 4-8-4 locomotives and additional S class locomotives did not come to fruition. The extra S class locomotives were never built and the line to Adelaide did not receive the necessary upgrades to take the weight of the H class.[23]
The A2's principal express passenger role continued into the postwar years as the VR, struggling with a backlog of repairs and limited capital expenditure, deferred new passenger locomotive construction. It was not until March 1946 when the first of the class, A2878, was withdrawn from service.[14]
In 1951, when the first of 70 new R class 4-6-4 express passenger locomotives were introduced, the A2 was finally superseded. In 1953, no fewer than 53 A2s went to scrap, followed by 36 more in 1954.[14] However, many of the class (particularly the later Walschaerts variants) continued on in secondary roles such as branch-line passenger and goods services and a number lasted into the 1960s. Their last regular mainline duty was hauling services between Flinders Street and Leongatha, on the South Gippsland line. The last in service, A2986, was withdrawn on 2 December 1963, exactly 56 years after the original A2572 entered service.[14][24]
Accidents
Some A2 locomotives were unfortunate enough to be involved in major accidents:
- At 2:58 am on 7 September 1951, the westbound and eastbound Overland expresses, both hauled by double-heading A2s, collided head-on at Serviceton.[25][26] All four locomotives were written off; three were so badly damaged they were scrapped on site.
- Australia's worst level crossing accident occurred on 8 May 1943, when A2863 collided with a bus carrying troops at Wodonga.[5] 25 people were killed.[27]
List of engines and renumberings
The A2 fleet was constructed in ten batches. All the Stephenson engines, batches 1 to 8, were constructed at the Victorian Railways' Newport Workshops. The same is true of Batch 9 and the first 20 engines of Batch 10. However, engines 1073–1077 (later 973–977) were built at Ballarat Workshops, and 1078–1082 (later 978–982) were built at Bendigo Workshops. There is no indication as to where engines 1083–1092 would have been constructed.
These tables are based on:
- Medlin, P. N. (2004) Victorian Railways Locomotives by Number (self-published, based on Victorian Railways' locomotive repair cards)
- Australian Railway History, August 2019 (Web extra)
- Victorian Railways locomotive record cards
Stephensons engines
Batch | Built | A2 (2nd) | A1 (1st) | A1 (2nd) | A1 or A2 (3rd) | Final ID | Front auto | Tender auto | Modified Front End | Smoke deflectors | Electric lights | Staff Exchanger | Off Register | Reason | Age | Notes | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1 | 1907-12-02 | A2 572 | 1925-08-05 | A2 805 | 19xx-xx-xx | A1 805 | - | - | - | - | 1940-03-05 | A2 825 | ? | ? | ? | ? | ? | ? | 1954-09-17 | Scrapped | 46 | Pattern engine. Different dome shape to rest of class, but not flat; swapped to normal by scrap date as A2 825. Some unsubstantiated claims of dark blue being used in the original livery in lieu of chocolate brown, but no evidence. |
1 | 1908-10-28 | A2 574 | 1925-05-25 | A2 807 | 19xx-xx-xx | A1 807 | - | - | - | - | 1946-12-24 | A2 878 | ? | ? | ? | ? | ? | ? | 1954-05-07 | Scrapped | 45 | - |
1 | 1908-10-30 | A2 576 | 1924-05-13 | A2 875 | 1930-09-xx | A1 806 | - | - | - | - | 1944-03-16 | A2 837 | ? | ? | ? | ? | ? | ? | 1952-01-04 | Scrapped | 43 | - |
1 | 1908-11-27 | A2 578 | 1925-04-14 | A2 876 | 1929-10-xx | A1 800 | - | - | - | - | 1932-06-xx | A2 869 | ? | ? | ? | ? | ? | ? | 1952-11-13 | Scrapped | 43 | - |
1 | 1908-12-09 | A2 580 | 1923-10-25 | A2 877 | 1929-05-xx | A1 877 | 1929-11-18 | A1 803 | - | - | 1941-02-22 | A2 845 | ? | ? | ? | ? | ? | ? | 1954-10-27 | Scrapped | 45 | - |
1 | 1908-12-21 | A2 722 | 1925-08-06 | A2 817 | 1930-04-xx | A1 817 | - | - | - | - | 1944-12-21 | A2 827 | ? | ? | ? | ? | ? | ? | 1961-03-27 | Scrapped | 52 | - |
1 | 1909-03-15 | A2 724 | 1924-12-16 | A2 819 | 1929-09-xx | A1 819 | - | - | - | - | 1933-12-16 | A2 854 | ? | ? | ? | ? | ? | ? | 1951-04-20 | Scrapped | 42 | - |
1 | 1909-03-30 | A2 726 | 1925-11-11 | A2 820 | - | - | - | - | - | - | 1931-12-xx | A2 870 | ? | ? | ? | ? | ? | ? | 1962-02-09 | Scrapped | 52 | - |
1 | 1909-04-08 | A2 728 | 1924-05-xx | A2 881 | 1928-01-xx | A1 804 | - | - | - | - | 1944-05-05 | A2 833 | ? | ? | ? | ? | ? | ? | 1954-12-09 | Scrapped | 45 | - |
1 | 1909-04-27 | A2 730 | 1925-11-25 | A2 822 | 1929-08-xx | A1 822 | - | - | - | - | 1933-09-13 | A2 861 | ? | ? | ? | ? | ? | ? | 1953-04-13 | Scrapped | 43 | - |
2 | 1910-02-09 | A2 752 | 1926-01-29 | A2 823 | - | - | - | - | - | - | 1926-09-02 | A2 887 | ? | ? | ? | ? | ? | ? | 1954-02-10 | Scrapped | 44 | - |
2 | 1910-02-26 | A2 754 | 1925-10-12 | A2 825 | - | - | - | - | - | - | 1929-08-01 | A2 883 | ? | ? | ? | ? | ? | ? | 1962-06-27 | Scrapped | 52 | - |
2 | 1910-03-04 | A2 756 | 1926-02-12 | A2 827 | 1929-11-xx | A1 827 | - | - | - | - | 1933-2-xx | A2 863 | ? | ? | ? | ? | ? | ? | 1953-12-18 | Scrapped | 43 | Collided with bus at Wodonga 8 May 1943, killed 25 people. |
2 | 1910-03-22 | A2 758 | 1925-08-26 | A2 829 | 1929-10-xx | A1 829 | - | - | - | - | 1932-06-xx | A2 867 | ? | ? | ? | ? | ? | ? | 1952-04-30 | Scrapped | 42 | - |
2 | 1910-04-18 | A2 760 | 1925-09-02 | A2 831 | - | - | - | - | - | - | 1929-10-xx | A2 882 | ? | ? | ? | ? | ? | ? | 1952-11-13 | Scrapped | 42 | - |
2 | 1910-05-10 | A2 762 | 1925-12-08 | A2 833 | 19xx-xx-xx | A1 833 | - | - | - | - | 1935-11-09 | A2 849 | ? | ? | ? | ? | ? | ? | 1953-03-13 | Scrapped | 42 | - |
2 | 1910-05-25 | A2 764 | 1925-04-18 | A2 835 | 19xx-xx-xx | A1 835 | - | - | - | - | 1935-05-10 | A2 852 | ? | ? | ? | ? | ? | ? | 1954-08-06 | Scrapped | 44 | - |
2 | 1910-06-16 | A2 766 | 1925-12-07 | A2 837 | 19xx-xx-xx | A1 837 | - | - | - | - | 1942-07-03 | A2 838 | ? | ? | ? | ? | ? | ? | 1951-03-03 | Scrapped | 40 | - |
2 | 1910-06-29 | A2 768 | 1925-09-04 | A2 840 | - | - | - | - | - | - | 1931-01-09 | A2 875 | ? | ? | ? | ? | ? | ? | 1954-09-30 | Scrapped | 44 | - |
2 | 1910-06-30 | A2 770 | 1925-11-30 | A2 841 | 19xx-xx-xx | A1 841 | 1941-08-07 | A1 803 | - | - | 19xx-xx-xx | A2 829 | ? | ? | ? | ? | ? | ? | 1952-05-14 | Scrapped | 41 | - |
3 | 1910-12-23 | A2 798 | 1925-10-08 | A2 842 | 1941-03-11 | A1 842 | 1949-10-07 | A1 808 | - | - | 1949-05-11 | A2 816 | 1934-06-29 | 1934-06-29 | 1938-09-22 | 1938-09-22 | 1942-06-10 | ? | 1955-04-21 | Scrapped | 44 | 11/5/49 assumed to avoid conflict with A1 816; index card is difficult to read.[28] |
3 | 1911-01-27 | A2 800 | - | - | - | - | - | - | - | - | 1929-12-16 | A2 876 | 1933-06-23 | 1933-06-23 | 1935-06-17 | 1935-06-17 | 1931-05-09 | 1935-06-17 | 1960-10-17 | Scrapped | 49 | Precipitated Brown Coal experiments 1923–1924. Fitted with shunters steps 31 August 1956.[29] |
3 | 1911-02-11 | A2 802 | - | - | 19xx-xx-xx | A1 802 | - | - | - | - | 1946-06-12 | A2 824 | 1933-02-25 | 1933-02-25 | 1935-10-12 | 1936-05-01 | 1941-01-28 | Y | 1950-12-08 | Scrapped | 39 | Smoke deflectors were "new type" |
3 | 1911-02-23 | A2 804 | - | - | - | - | - | - | - | - | 1926-08-07 | A2 885 | ? | ? | ? | ? | ? | ? | 1956-02-28 | Scrapped | 45 | - |
3 | 1911-03-08 | A2 806 | - | - | - | - | - | - | - | - | 1926-08-03 | A2 886 | ? | ? | ? | ? | ? | ? | 1954-02-10 | Scrapped | 42 | - |
3 | 1911-03-21 | A2 808 | - | - | 19xx-xx-xx | A1 808 | - | - | - | - | 1933-12-21 | A2 855 | ? | ? | ? | ? | ? | ? | 1956-07-02 | Scrapped | 45 | - |
3 | 1911-03-31 | A2 810 | - | - | 9/1929 | A1 810 | - | - | - | - | 1935-09-07 | A2 851 | ? | ? | ? | ? | ? | ? | 1955-12-21 | Scrapped | 44 | - |
3 | 1911-04-11 | A2 812 | - | - | 19xx-xx-xx | A1 812 | - | - | - | - | 1933-12-05 | A2 856 | ? | ? | ? | ? | ? | ? | 1951-08-30 | Scrapped | 40 | - |
3 | 1911-04-28 | A2 814 | - | - | - | - | - | - | - | - | 1929-09-xx | A2 881 | ? | ? | ? | ? | ? | ? | 1959-10-09 | Scrapped | 48 | - |
3 | 1911-05-09 | A2 816 | - | - | 1929-09-12 | A1 816 | - | - | - | - | 1949-04-01 | A2 818 | 1933-06-30 | 1933-06-30 | 1937-10-15 | 1937-10-15 | 9/1927 | 1941-02-05 | 1953-02-13 | Scrapped | 41 | - |
4 | 1911-06-27 | A2 818 | - | - | 5/1931 | A1 818 | - | - | - | - | 1934-10-31 | A2 853 | ? | ? | ? | ? | ? | ? | 1953-04-13 | Scrapped | 41 | - |
4 | 1911-06-30 | A2 820 | - | - | - | - | - | - | - | - | 1925-10-24 | A2 898 | ? | ? | ? | ? | ? | ? | 1952-11-07 | Scrapped | 41 | - |
4 | 1911-07-20 | A2 822 | - | - | - | - | - | - | - | - | 1925-08-26 | A2 900 | ? | ? | ? | ? | ? | ? | 1951-09-03 | Scrapped | 40 | - |
4 | 1911-08-01 | A2 824 | - | - | 19xx-xx-xx | A1 824 | - | - | - | - | 1946-01-24 | A2 826 | ? | ? | ? | ? | ? | ? | 1960-07-01 | Scrapped | 48 | Confirm 1946 not 1926 – ref. ID cards. Fitted with shunters steps 17 May 1954.[29] |
4 | 1911-08-16 | A2 826 | - | - | - | - | - | - | - | - | 1931-07-xx | A2 871 | ? | ? | ? | ? | ? | ? | 1951-01-25 | Scrapped | 39 | - |
4 | 1911-08-26 | A2 828 | - | - | 7/1931 | A1 828 | - | - | - | - | 19xx-xx-xx | A2 873 | ? | ? | ? | ? | ? | ? | 1955-07-28 | Scrapped | 43 | - |
4 | 1911-09-09 | A2 830 | - | - | 19xx-xx-xx | A1 830 | - | - | - | - | 1933-02-13 | A2 864 | ? | ? | ? | ? | ? | ? | 1954-04-02 | Scrapped | 42 | - |
4 | 1911-09-19 | A2 832 | - | - | - | - | - | - | - | - | 1931-08-xx | A2 872 | ? | ? | ? | ? | ? | ? | 1953-09-18 | Scrapped | 41 | - |
4 | 1911-09-27 | A2 834 | - | - | 19xx-xx-xx | A1 858 | - | - | - | - | 1933-10-09 | A2 858 | ? | ? | ? | ? | ? | ? | 1953-07-30 | Scrapped | 41 | - |
6 | 1911-10-01 | A2 853 | - | - | - | - | - | - | - | - | 1925-08-03 | A2 918 | ? | ? | ? | ? | ? | ? | 1953-06-19 | Scrapped | 41 | - |
4 | 1911-10-04 | A2 836 | - | - | 19xx-xx-xx | A1 836 | - | - | - | - | 1932-12-15 | A2 865 | ? | ? | ? | ? | ? | ? | 1956-09-29 | Scrapped | 44 | - |
5 | 1912-09-13 | A2 799 | - | - | - | - | - | - | - | - | 1924-10-29 | A2 890 | ? | ? | ? | ? | ? | ? | 1950-09-28 | Scrapped | 38 | - |
5 | 1912-09-20 | A2 801 | - | - | 19xx-xx-xx | A1 801 | - | - | - | - | 1941-05-02 | A2 842 | ? | ? | ? | ? | ? | ? | 1953-08-26 | Scrapped | 40 | - |
5 | 1912-09-28 | A2 803 | - | - | - | - | - | - | - | - | 1930-02-xx | A2 877 | ? | ? | ? | ? | ? | ? | 1954-01-18 | Scrapped | 41 | - |
5 | 1912-10-05 | A2 805 | - | - | - | - | - | - | - | - | 1925-06-29 | A2 891 | ? | ? | ? | ? | ? | ? | 1952-12-05 | Scrapped | 40 | - |
5 | 1912-10-12 | A2 807 | - | - | - | - | - | - | - | - | 1925-02-27 | A2 892 | ? | ? | ? | ? | ? | ? | 1952-10-13 | Scrapped | 40 | - |
5 | 1912-10-19 | A2 809 | - | - | - | - | - | - | - | - | 1925-05-06 | A2 893 | ? | ? | ? | ? | ? | ? | 1954-05-14 | Scrapped | 41 | - |
5 | 1912-10-29 | A2 811 | - | - | 1926-09-21 | A1 811 | - | - | - | - | 1948-07-23 | A2 820 | 1936-12-21 | 1936-12-21 | 1936-12-21 | 1936-12-21 | 1941-07-01 | 1948-07-23 | 1953-06-18 | Scrapped | 40 | 21 Sep 1926 is a guess based on ink shade.[28] |
5 | 1912-11-04 | A2 813 | - | - | - | - | - | - | - | - | 1925-05-13 | A2 894 | ? | ? | ? | ? | ? | ? | 1956-11-22 | Scrapped | 44 | Fitted with shunters steps, date unknown.[29] |
5 | 1912-11-11 | A2 815 | - | - | - | - | - | - | - | - | 1925-02-11 | A2 895 | ? | ? | ? | ? | ? | ? | 1951-09-04 | Scrapped | 38 | - |
5 | 1912-11-18 | A2 817 | - | - | - | - | - | - | - | - | 1925-07-20 | A2 896 | ? | ? | ? | ? | ? | ? | 1953-03-20 | Scrapped | 40 | - |
5 | 1912-11-26 | A2 819 | - | - | - | - | - | - | - | - | 1924-12-09 | A2 897 | ? | ? | ? | ? | ? | ? | 1953-12-15 | Scrapped | 41 | - |
5 | 1912-12-03 | A2 821 | - | - | - | - | - | - | - | - | 1925-11-23 | A2 899 | ? | ? | ? | ? | ? | ? | 1951-09-26 | Scrapped | 38 | - |
5 | 1912-12-10 | A2 823 | - | - | - | - | - | - | - | - | 1926-01-19 | A2 901 | ? | ? | ? | ? | ? | ? | 1951-05-31 | Scrapped | 38 | - |
5 | 1912-12-16 | A2 825 | - | - | - | - | - | - | - | - | 1925-09-24 | A2 902 | ? | ? | ? | ? | ? | ? | 1954-04-22 | Scrapped | 41 | - |
5 | 1912-12-20 | A2 827 | - | - | - | - | - | - | - | - | 1926-02-09 | A2 903 | ? | ? | ? | ? | ? | ? | 1956-01-27 | Scrapped | 43 | Fitted with shunters steps 14 September 1956.[29] |
5 | 1913-01-24 | A2 829 | - | - | - | - | - | - | - | - | 1925-06-14 | A2 904 | ? | ? | ? | ? | ? | ? | 1947-07-31 | Scrapped | 34 | Scrapped following a collision with obstructing goods wagons at Riddells Creek on 1 July 1947[30] |
5 | 1913-02-03 | A2 831 | - | - | - | - | - | - | - | - | 1925-06-19 | A2 905 | ? | ? | ? | ? | ? | ? | 1953-12-09 | Scrapped | 40 | - |
5 | 1913-02-11 | A2 833 | - | - | - | - | - | - | - | - | 1925-08-25 | A2 906 | ? | ? | ? | ? | ? | ? | 1954-01-30 | Scrapped | 40 | - |
5 | 1913-02-21 | A2 835 | - | - | - | - | - | - | - | - | 1925-04-08 | A2 907 | ? | ? | ? | ? | ? | ? | 1953-06-05 | Scrapped | 40 | - |
5 | 1913-02-28 | A2 837 | - | - | - | - | - | - | - | - | 1925-08-25 | A2 908 | ? | ? | ? | ? | ? | ? | 1951-07-07 | Scrapped | 38 | - |
5 | 1913-03-11 | A2 839 | - | - | 1933-03-02 | A2 857 | - | - | - | - | 1933-03-02 | A2 857 | ? | ? | ? | ? | ? | ? | 1953-01-16 | Scrapped | 39 | - |
5 | 1913-03-19 | A2 841 | - | - | - | - | - | - | - | - | 1925-09-21 | A2 910 | ? | ? | ? | ? | ? | ? | 1957-02-08 | Scrapped | 43 | - |
5 | 1913-03-31 | A2 843 | - | - | 1933-12-05 | A1 843 | 1941-02-21 | A1 812 | - | - | 1949-04-01 | A2 817 | 1934-10-06 | 1934-10-06 | 10/1934 | 1936-02-05 | 1941-12-20 | 1949-04-01 | 1953-10-30 | Scrapped | 40 | - |
5 | 1913-04-14 | A2 845 | - | - | - | - | - | - | - | - | 1926-02-10 | A2 913 | ? | ? | ? | ? | ? | ? | 1953-02-06 | Scrapped | 39 | - |
5 | 1913-04-24 | A2 847 | - | - | - | - | - | - | - | - | 1925-08-07 | A2 914 | ? | ? | ? | ? | ? | ? | 1953-11-26 | Scrapped | 40 | - |
6 | 1913-07-26 | A2 838 | - | - | 1929-12-xx | A1 838 | - | - | - | - | 1941-08-xx | A2 841 | ? | ? | ? | ? | ? | ? | 1959-10-19 | Scrapped | 46 | - |
6 | 1913-08-02 | A2 840 | - | - | - | - | - | - | - | - | 1925-05-14 | A2 909 | ? | ? | ? | ? | ? | ? | 1955-01-12 | Scrapped | 41 | - |
6 | 1913-08-09 | A2 842 | - | - | - | - | - | - | - | - | 1925-04-04 | A2 911 | ? | ? | ? | ? | ? | ? | 1950-02-21 | Scrapped | 36 | - |
6 | 1913-08-16 | A2 844 | - | - | - | - | - | - | - | - | 1925-12-10 | A2 912 | ? | ? | ? | ? | ? | ? | 1953-09-18 | Scrapped | 40 | - |
6 | 1913-08-23 | A2 846 | - | - | 19xx-xx-xx | A1 846 | 1933-12-29 | A1 827 | - | - | 1944-11-10 | A2 830 | ? | ? | ? | ? | ? | ? | 1953-07-01 | Scrapped | 39 | - |
6 | 1913-08-29 | A2 848 | - | - | - | - | - | - | - | - | 1929-07-xx | A2 884 | ? | ? | ? | ? | ? | ? | 1954-07-30 | Preserved | 40 | ARHS Newport |
6 | 1913-09-04 | A2 849 | - | - | - | - | - | - | - | - | 1925-02-03 | A2 916 | ? | ? | ? | ? | ? | ? | 1946-08-03 | Scrapped | 32 | - |
6 | 1913-09-10 | A2 850 | - | - | - | - | - | - | - | - | 1925-09-03 | A2 917 | ? | ? | ? | ? | ? | ? | 1952-11-07 | Scrapped | 39 | - |
6 | 1913-09-18 | A2 851 | - | - | - | - | - | - | - | - | 1929-10-xx | A2 879 | ? | ? | ? | ? | ? | ? | 1954-03-26 | Scrapped | 40 | - |
6 | 1913-09-24 | A2 852 | - | - | 6/1931 | A1 852 | 1933-01-28 | A1 829 | - | - | 1940-07-12 | A2 846 | ? | ? | ? | ? | ? | ? | 1954-07-23 | Scrapped | 40 | - |
6 | 1913-10-08 | A2 854 | - | - | 1929-12-xx | A1 854 | 1933-01-27 | A1 832 | 1944-01-xx | A1 801 | 1946-11-xx | A2 821 | 1939-02-17 | 1939-02-17 | 1939-02-17 | 1939-02-17 | 1941-04-05 | 1946-11-15 | 1953-10-09 | Scrapped | 40 | - |
6 | 1913-10-15 | A2 855 | - | - | 19xx-xx-xx | A1 855 | 1933-09-21 | A1 840 | 1941-06-26 | A1 810 | 1944-06-11 | A2 832 | ? | ? | ? | ? | ? | ? | 1953-09-14 | Scrapped | 39 | - |
6 | 1913-10-21 | A2 856 | - | - | - | - | - | - | - | - | 1926-06-12 | A2 919 | ? | ? | ? | ? | ? | ? | 1954-02-19 | Scrapped | 40 | - |
6 | 1913-10-30 | A2 857 | - | - | - | - | - | - | - | - | 1925-09-01 | A2 921 | ? | ? | ? | ? | ? | ? | 1953-03-24 | Scrapped | 39 | - |
7 | 1913-11-05 | A2 858 | - | - | - | - | - | - | - | - | 1925-07-03 | A2 925 | ? | ? | ? | ? | ? | ? | 1953-10-02 | Scrapped | 39 | - |
7 | 1913-11-12 | A2 859 | - | - | 1933-01-23 | A1 828 | - | - | - | - | 1944-09-22 | A2 831 | ? | ? | ? | ? | ? | ? | 1953-10-02 | Scrapped | 39 | - |
7 | 1913-11-19 | A2 860 | - | - | 1929-12-xx | A1 860 | - | - | - | - | 19xx-xx-xx | A2 860 | ? | ? | ? | ? | ? | ? | 1953-04-13 | Scrapped | 39 | - |
7 | 1913-11-26 | A2 861 | - | - | - | - | - | - | - | - | 1925-09-29 | A2 926 | ? | ? | ? | ? | ? | ? | 1951-02-19 | Scrapped | 37 | - |
7 | 1913-12-03 | A2 862 | - | - | - | - | - | - | - | - | 1925-06-23 | A2 927 | ? | ? | ? | ? | ? | ? | 1964-11-15 | Scrapped | 50 | - |
7 | 1913-12-11 | A2 863 | - | - | - | - | - | - | - | - | 1929-10-xx | A2 878 | ? | ? | ? | ? | ? | ? | 1946-03-25 | Wrecked | 32 | - |
7 | 1913-12-16 | A2 864 | - | - | - | - | - | - | - | - | 1925-08-24 | A2 930 | ? | ? | ? | ? | ? | ? | 1953-12-04 | Scrapped | 39 | - |
7 | 1913-12-20 | A2 865 | - | - | 19xx-xx-xx | A1 865 | 1932-01-xx | A1 825 | - | - | 1944-10-xx | A2 828 | ? | ? | ? | ? | ? | ? | 1960-10-22 | Scrapped | 46 | - |
7 | 1913-12-22 | A2 866 | - | - | - | - | - | - | - | - | 1925-06-20 | A2 932 | ? | ? | ? | ? | ? | ? | 1962-03-27 | Scrapped | 48 | - |
7 | 1914-01-22 | A2 867 | - | - | 19xx-xx-xx | A1 867 | 1932-01-xx | A1 823 | - | - | 1944-02-25 | A2 836 | ? | ? | ? | ? | ? | ? | 1956-03-21 | Scrapped | 42 | - |
7 | 1914-01-30 | A2 868 | - | - | 9/1929 | A1 868 | - | - | - | - | 1931-3-xx | A2 868 | ? | ? | ? | ? | ? | ? | 1953-05-12 | Scrapped | 39 | - |
7 | 1914-02-07 | A2 869 | - | - | 4/1931 | A1 869 | 4/1931 | A1 821 | 1946-07-29 | A1 814 | 1948-11-05 | A2 819 | 1934-06-23 | 1934-06-23 | 1938-03-01 | 1938-03-01 | 1942-01-27 | 1948-11-05 | 1953-07-08 | Scrapped | 39 | - |
7 | 1914-02-14 | A2 870 | - | - | 4/1930 | A1 870 | 4/1931 | A1 815 | - | - | 1942-02-13 | A2 839 | ? | ? | ? | ? | ? | ? | 1954-02-12 | Scrapped | 39 | - |
7 | 1914-02-21 | A2 871 | - | - | 19xx-xx-xx | A1 871 | 1931-04-xx | A1 814 | - | - | 1948-11-05 | A2 834 | ? | ? | ? | ? | ? | ? | 1960-05-20 | Scrapped | 46 | Fitted with shunters steps 17 May 1954.[29] |
7 | 1914-02-28 | A2 872 | - | - | - | - | - | - | - | - | 1926-10-16 | A2 933 | ? | ? | ? | ? | ? | ? | 1953-11-27 | Scrapped | 39 | - |
8 | 1914-07-29 | A2 913 | 1926-01-22 | A2 845 | 19xx-xx-xx | A1 845 | 1933-12-29 | A1 809 | - | - | 1946-05-xx | A2 823 | 1934-10-06 | 1930-12-25 | 1934-10-06 | 1936-04-30 | 1942-01-12 | 1946-05-24 | 1959-07-13 | Scrapped | 44 | Smoke deflectors were "new type" |
8 | 1914-08-05 | A2 914 | 1925-08-07 | A2 847 | - | - | - | - | - | - | 1929-12-xx | A2 874 | ? | ? | ? | ? | ? | ? | 1963-02-08 | Scrapped | 48 | - |
8 | 1914-08-12 | A2 915 | - | - | - | - | - | - | - | - | No change | A2 915 | ? | ? | ? | ? | ? | ? | 1955-01-20 | Scrapped | 40 | - |
8 | 1914-08-18 | A2 916 | 1925-09-03 | A2 849 | 19xx-xx-xx | A1 849 | 1933-12-25 | A1 822 | - | - | 1936-05-16 | A2 848 | ? | ? | ? | ? | ? | ? | 1955-01-20 | Scrapped | 40 | - |
8 | 1914-08-28 | A2 917 | 1925-12-19 | A2 850 | 1929-11-xx | A1 850 | - | - | - | - | 1933-03-18 | A2 850 | ? | ? | ? | ? | ? | ? | 1953-05-15 | Scrapped | 38 | - |
8 | 1914-09-24 | A2 918 | 1925-08-25 | A2 853 | 19xx-xx-xx | A1 853 | - | - | - | - | 1933-05-27 | A2 862 | ? | ? | ? | ? | ? | ? | 1952-08-29 | Scrapped | 37 | - |
8 | 1914-10-09 | A2 919 | 1926-09-01 | A2 856 | 9/1926 | A1 856 | 7/1933 | A1 844 | - | - | 19xx-xx-xx | A2 844 | ? | ? | ? | ? | ? | ? | 1956-06-05 | Scrapped | 41 | - |
8 | 1914-10-14 | A2 920 | - | - | - | - | - | - | - | - | No change | A2 920 | ? | ? | ? | ? | ? | ? | 1953-05-22 | Scrapped | 38 | - |
8 | 1914-10-20 | A2 921 | 1925-11-27 | A2 888 | - | - | - | - | - | - | 1925-11-27 | A2 888 | 1934-06-09 | 1934-06-09 | 1936-11-12 | 1936-11-12 | 1938-05-21 | 1936-11-12 | 1955-11-21 | Scrapped | 41 | Fitted with welded, fabricated wheel centres from 31-07-1951. Restricted to goods working only whilst fitted. Looked similar to Southern Rail's disc wheels, designed by the VR's Ted Wohlfahrt and bore no resemblance to BoxPok wheel centres.[31] |
8 | 1914-10-24 | A2 922 | - | - | - | - | - | - | - | - | No change | A2 922 | ? | ? | ? | ? | ? | ? | 1954-03-31 | Scrapped | 39 | - |
8 | 1914-10-31 | A2 923 | - | - | - | - | - | - | - | - | No change | A2 923 | ? | ? | ? | ? | ? | ? | 1960-10-05 | Scrapped | 45 | Fitted with shunters steps 7 September 1956.[29] |
8 | 1914-11-07 | A2 924 | - | - | - | - | - | - | - | - | No change | A2 924 | ? | ? | ? | ? | ? | ? | 1953-04-10 | Scrapped | 38 | - |
8 | 1914-11-14 | A2 925 | 1926-08-xx | A2 858 | 1925-08-13 | A1 826 | - | - | - | - | 1936-05-23 | A2 847 | ? | ? | ? | ? | ? | ? | 1953-01-23 | Scrapped | 38 | - |
8 | 1914-11-27 | A2 926 | 1925-09-02 | A2 861 | 19xx-xx-xx | A1 861 | 1933-01-14 | A1 820 | - | - | 1933-01-14 | A2 843 | ? | ? | ? | ? | ? | ? | 1953-06-11 | Scrapped | 38 | - |
8 | 1914-11-28 | A2 927 | 1925-06-23 | A2 862 | 7/1929 | A1 862 | - | - | 1933-01-10 | A2 800 | 1944-03-18 | A2 835 | ? | ? | ? | ? | ? | ? | 1951-01-13 | Scrapped | 36 | - |
8 | 1914-12-08 | A2 928 | - | - | - | - | - | - | - | - | No change | A2 928 | ? | ? | ? | ? | ? | ? | 1956-06-01 | Scrapped | 41 | - |
8 | 1914-12-12 | A2 929 | - | - | - | - | - | - | - | - | No change | A2 929 | ? | ? | ? | ? | ? | ? | 1955-10-21 | Scrapped | 40 | - |
8 | 1914-12-17 | A2 930 | 1925-08-20 | A2 864 | 1932-01-xx | A1 831 | - | - | - | - | 1941-06-25 | A2 840 | ? | ? | ? | ? | ? | ? | 1954-05-25 | Scrapped | 39 | - |
8 | 1914-12-22 | A2 931 | - | - | - | - | - | - | - | - | No change | A2 931 | ? | ? | ? | ? | ? | ? | 1953-10-12 | Scrapped | 38 | - |
8 | 1914-12-23 | A2 932 | 1925-07-07 | A2 866 | - | - | - | - | - | - | 1925-07-07 | A2 866 | ? | ? | ? | ? | ? | ? | 1963-05-12 | Scrapped | 48 | - |
8 | 1915-01-20 | A2 933 | 1926-08-25 | A2 872 | 4/1931 | A1 813 | - | - | - | - | 1946-07-25 | A2 822 | 1933-08-12 | 1933-08-12 | 1938-08-18 | 1938-08-18 | 1941-10-10 | Y | 1961-02-27 | Scrapped | 46 | - |
8 | 1915-01-29 | A2 934 | - | - | - | - | - | - | - | - | No change | A2 934 | ? | ? | ? | ? | ? | ? | 1961-02-27 | Scrapped | 46 | - |
8 | 1915-02-03 | A2 935 | - | - | - | - | - | - | - | - | No change | A2 935 | ? | ? | ? | ? | ? | ? | 1954-10-08 | Scrapped | 39 | - |
8 | 1915-02-11 | A2 936 | - | - | - | - | - | - | - | - | No change | A2 936 | ? | ? | ? | ? | ? | ? | 1954-05-03 | Scrapped | 39 | - |
8 | 1915-02-16 | A2 937 | - | - | - | - | - | - | - | - | No change | A2 937 | ? | ? | ? | ? | ? | ? | 1955-01-19 | Scrapped | 39 | - |
8 | 1915-02-27 | A2 938 | 1924-11-27 | A2 873 | 1931-03-12 | A1 809 | - | - | - | - | 1933-09-19 | A2 859 | ? | ? | ? | ? | ? | ? | 1951-04-09 | Scrapped | 36 | 19/9/33 or 29/9/33 |
8 | 1915-03-03 | A2 939 | 1925-06-03 | A2 874 | - | - | - | - | - | - | 1929-07-xx | A2 880 | ? | ? | ? | ? | ? | ? | 1953-01-19 | Scrapped | 37 | - |
8 | 1915-03-10 | A2 940 | 1925-09-16 | A2 938 | - | - | - | - | - | - | 1925-09-16 | A2 938 | ? | ? | ? | ? | ? | ? | 1961-01-27 | Scrapped | 45 | - |
8 | 1915-03-17 | A2 941 | 1925-08-07 | A2 939 | - | - | - | - | - | - | 1925-08-07 | A2 939 | ? | ? | ? | ? | ? | ? | 1959-06-16 | Scrapped | 44 | - |
8 | 1915-03-24 | A2 942 | 1924-07-30 | A2 902 | - | - | - | - | - | - | 1925-11-24 | A2 889 | ? | ? | ? | ? | ? | ? | 1956-06-12 | Scrapped | 41 | - |
Walschaerts engines
Batch | Built | Final ID | Front auto | Tender auto | Modified Front End | Smoke deflectors | Electric lights | Staff Exchanger | Conversion to oil | Tank type (may not be accurate)[32] | Off Register | Reason | Age | Notes | ||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
9 | 1915-10-23 | A2 983 | No change | A2 983 | ? | ? | ? | ? | ? | ? | Y | Square | 1955-06-14 | Scrapped | 39 | - |
9 | 1915-11-01 | A2 984 | No change | A2 984 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1954-05-12 | Scrapped | 38 | - |
9 | 1915-11-09 | A2 985 | No change | A2 985 | ? | ? | ? | ? | ? | ? | Y | Square | 1953-05-29 | Scrapped | 37 | - |
9 | 1915-11-18 | A2 986 | No change | A2 986 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1964-01-15 | Preserved | 48 | Boxpok wheels from May 1948.[33] Preserved Warragul, then to Steamrail Victoria (swapped for J550). Restored to working order as coal-burner. |
9 | 1915-11-30 | A2 987 | No change | A2 987 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-11-26 | Scrapped | 38 | - |
9 | 1915-12-11 | A2 988 | No change | A2 988 | ? | ? | ? | ? | ? | ? | Y | Square | 1957-03-01 | Scrapped | 41 | - |
9 | 1915-12-23 | A2 989 | No change | A2 989 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1954-11-25 | Scrapped | 38 | - |
9 | 1916-01-11 | A2 990 | No change | A2 990 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1962-03-21 | Scrapped | 46 | - |
9 | 1916-03-31 | A2 991 | No change | A2 991 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1953-06-15 | Scrapped | 37 | - |
9 | 1916-08-23 | A2 992 | No change | A2 992 | ? | ? | ? | ? | ? | ? | Y | Square | 1953-08-07 | Scrapped | 36 | Boxpok wheels from Aug 1948.[33] |
9 | 1916-04-15 | A2 993 | No change | A2 993 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1959-06-12 | Scrapped | 43 | - |
9 | 1916-05-10 | A2 994 | No change | A2 994 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1962-02-09 | Scrapped | 45 | - |
9 | 1916-06-29 | A2 995 | No change | A2 995 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1963-09-13 | Preserved | 47 | ARHS Newport |
9 | 1916-06-09 | A2 996 | No change | A2 996 | ? | ? | ? | ? | ? | ? | Y | Square | 1963-11-22 | Preserved | 47 | Static at Echuca wharf |
9 | 1917-06-30 | A2 997 | No change | A2 997 | ? | ? | ? | ? | ? | ? | Y | Square | 1953-01-12 | Scrapped | 35 | - |
9 | 1918-05-10 | A2 998 | No change | A2 998 | ? | ? | ? | ? | ? | ? | n/a | n/a | 1947-08-04 | Scrapped | 29 | - |
9 | 1918-06-25 | A2 999 | No change | A2 999 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-04-15 | Scrapped | 35 | - |
9 | 1918-07-24 | A2 1000 | 1925-08-27 | A2 940 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-09-23 | Scrapped | 36 | - |
9 | 1918-08-17 | A2 1001 | 1925-11-05 | A2 941 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1959-11-01 | Scrapped | 41 | - |
9 | 1918-08-25 | A2 1002 | 1924-09-27 | A2 942 | ? | ? | ? | ? | ? | ? | Y | Square | 1957-01-24 | Scrapped | 38 | - |
9 | 1918-10-29 | A2 1003 | 1924-05-06 | A2 943 | ? | ? | ? | ? | ? | ? | Y | Square | 1956-08-27 | Scrapped | 37 | - |
9 | 1918-11-27 | A2 1004 | 1925-02-27 | A2 944 | 1935-05-25 | 1935-05-25 | 1935-05-25 | 1935-12-17 | 1930-09-10 | 1935-05-25 | 1946-07-11 | Cylindrical | 1954-11-12 | Scrapped | 35 | Boxpok wheels from Dec 1948[33] |
9 | 1918-12-20 | A2 1005 | 1925-06-30 | A2 945 | ? | ? | ? | ? | ? | ? | Y | Square | 1958-10-31 | Scrapped | 39 | - |
9 | 1919-02-07 | A2 1006 | 1924-04-30 | A2 946 | ? | ? | ? | ? | ? | ? | Y | Square | 1953-10-09 | Scrapped | 34 | Involved in Serviceton disaster, 1951. Only engine repaired. |
9 | 1919-03-13 | A2 1007 | 1925-08-26 | A2 947 | ? | ? | ? | ? | ? | ? | Y | Square | 1962-04-09 | Scrapped | 43 | - |
9 | 1919-04-15 | A2 1008 | 1925-12-16 | A2 948 | ? | ? | ? | ? | ? | ? | Y | Square | 1952-09-18 | Scrapped | 33 | Boxpok wheels from Nov 1947[33] |
9 | 1919-05-27 | A2 1009 | 1925-08-11 | A2 949 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-10-15 | Scrapped | 35 | - |
9 | 1919-06-12 | A2 1010 | 1925-07-23 | A2 950 | ? | ? | ? | ? | ? | ? | Y | Square | 1955-02-17 | Scrapped | 35 | - |
9 | 1919-06-28 | A2 1011 | 1924-05-31 | A2 951 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-05-05 | Scrapped | 34 | - |
9 | 1919-08-09 | A2 1012 | 1925-02-10 | A2 952 | ? | ? | ? | ? | ? | ? | Y | Square | 1956-04-30 | Scrapped | 36 | - |
10 | 1920-05-12 | A2 1053 | 1925-08-11 | A2 953 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1952-01-04 | Wrecked | 31 | Involved in Serviceton disaster, 1951. Scrapped on site. |
10 | 1920-07-05 | A2 1054 | 1926-01-11 | A2 954 | ? | ? | ? | ? | ? | ? | Y | Square | 1955-04-06 | Scrapped | 34 | - |
10 | 1920-08-03 | A2 1055 | 1925-09-04 | A2 955 | ? | ? | ? | ? | ? | ? | Y | Square | 1961-03-09 | Scrapped | 40 | - |
10 | 1920-08-24 | A2 1056 | 1925-12-18 | A2 956 | ? | ? | ? | ? | ? | ? | n/a | n/a | 1946-08-03 | Scrapped | 25 | - |
10 | 1920-09-16 | A2 1057 | 1925-05-29 | A2 957 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1953-07-10 | Scrapped | 32 | - |
10 | 1920-10-09 | A2 1058 | 1925-06-12 | A2 958 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1952-01-04 | Wrecked | 31 | Involved in Serviceton disaster, 1951. Scrapped on site. |
10 | 1920-10-28 | A2 1059 | 1925-05-23 | A2 959 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-10-22 | Scrapped | 33 | - |
10 | 1920-11-20 | A2 1060 | 1925-06-23 | A2 960 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-06-24 | Scrapped | 33 | - |
10 | 1920-12-11 | A2 1061 | 1925-06-02 | A2 961 | ? | ? | ? | ? | ? | ? | Y | Square | 1953-02-27 | Scrapped | 32 | - |
10 | 1920-12-22 | A2 1062 | 1925-06-29 | A2 962 | ? | ? | ? | ? | ? | ? | Y | Square | 1956-02-03 | Scrapped | 35 | - |
10 | 1921-03-24 | A2 1063 | 1923-10-26 | A2 963 | ? | ? | ? | ? | ? | ? | Y | Square | 1956-03-22 | Scrapped | 34 | - |
10 | 1921-04-15 | A2 1064 | 1924-10-29 | A2 964 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1964-01-15 | Preserved | 42 | Boxpok wheels from Sep 1947.[33] Preserved Reservoir. |
10 | 1921-05-05 | A2 1065 | 1926-01-07 | A2 965 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-03-26 | Scrapped | 32 | - |
10 | 1921-05-27 | A2 1066 | 1925-09-23 | A2 966 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1954-03-19 | Scrapped | 32 | - |
10 | 1921-06-17 | A2 1067 | 1926-11-23 | A2 967 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1955-07-18 | Scrapped | 34 | - |
10 | 1921-07-06 | A2 1068 | 1926-02-11 | A2 968 | ? | ? | ? | ? | ? | ? | Y | Square | 1955-10-07 | Scrapped | 34 | - |
10 | 1921-07-26 | A2 1069 | 1926-08-04 | A2 969 | ? | ? | ? | ? | ? | ? | Y | Square | 1953-01-06 | Scrapped | 31 | - |
10 | 1921-08-13 | A2 1070 | 1925-05-04 | A2 970 | ? | ? | ? | ? | ? | ? | n/a | n/a | 1946-08-03 | Scrapped | 24 | - |
10 | 1921-09-02 | A2 1071 | 1923-11-30 | A2 971 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1960-09-14 | Scrapped | 39 | - |
10 | 1921-09-21 | A2 1072 | 1923-10-27 | A2 972 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-03-05 | Scrapped | 32 | - |
10 | 1921-09-30 | A2 1073 | 1925-10-16 | A2 973 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1957-02-22 | Scrapped | 35 | ACFI Feedwater heater 1936-1944 |
10 | 1921-11-16 | A2 1078 | 1925-05-18 | A2 978 | ? | ? | ? | ? | ? | ? | Y | Square | 1958-09-19 | Scrapped | 36 | - |
10 | 1921-11-21 | A2 1079 | 1923-12-11 | A2 979 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1953-11-20 | Scrapped | 31 | - |
10 | 1921-11-28 | A2 1074 | 1923-11-29 | A2 974 | ? | ? | ? | ? | ? | ? | Y | Square | 1958-09-25 | Scrapped | 36 | - |
10 | 1922-02-09 | A2 1075 | 1924-01-12 | A2 975 | ? | ? | ? | ? | ? | ? | n/a | n/a | 1950-01-24 | Scrapped | 27 | - |
10 | 1922-03-13 | A2 1080 | 1924-04-07 | A2 980 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1954-11-05 | Scrapped | 32 | - |
10 | 1922-04-21 | A2 1076 | 1924-08-21 | A2 976 | ? | ? | ? | ? | ? | ? | Y | Square | 1957-02-19 | Scrapped | 34 | - |
10 | 1922-06-08 | A2 1081 | 1926-01-26 | A2 981 | ? | ? | ? | ? | ? | ? | Y | Square | 1954-09-10 | Scrapped | 32 | - |
10 | 1922-06-26 | A2 1077 | 1924-03-29 | A2 977 | ? | ? | ? | ? | ? | ? | Y | Square | 1952-01-04 | Wrecked | 29 | Involved in Serviceton disaster, 1951. Scrapped on site. |
10 | 1922-06-29 | A2 1082 | 1926-01-15 | A2 982 | ? | ? | ? | ? | ? | ? | Y | Cylindrical | 1957-05-17 | Scrapped | 34 | - |
10 | Not built | A2 1083 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
10 | Not built | A2 1084 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
10 | Not built | A2 1085 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
10 | Not built | A2 1086 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
10 | Not built | A2 1087 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
10 | Not built | A2 1088 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
10 | Not built | A2 1089 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
10 | Not built | A2 1090 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
10 | Not built | A2 1091 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
10 | Not built | A2 1092 | - | - | - | - | - | - | - | - | - | - | - | - | - | 10th order was for 40 engines but only 30 built.[34] |
Preservation
Only one of the original batch of 125 Stephenson A2 locomotives survives; 1913-built A2884 is today preserved at the Newport Railway Museum, along with (Walschaerts) A2995.[14] The museum notes that A2884 ran a total 1,002,624 miles (1,613,567 km) and A2995 a total 1,270,404 miles (2,044,517 km) during their service lives.[35]
A2964 is preserved at Edwardes Lake Park, Reservoir and A2996 in Echuca.[14]
After a 32-year-long effort, Steamrail Victoria restored A2986 to full working order as a coal burner. It first moved under steam on 30 May 2015 and entered service with Steamrail on 13 May 2017.
References
- 1 2 3 4 Pearce et al., p. 12
- ↑ "steamlocomotive.com Locobase #2385". Archived from the original on 27 September 2007. Retrieved 2 October 2006.
- ↑ Pearce et al., p. 21
- ↑ "VPRS 12800/P1 H 1667 - PUBLIC RECORD OFFICE VICTORIA - A2 CLASS STEAM LOCOMOTIVE No.906 GEELONG FLIER FIRST TRIP". Public Record Office Victoria. Archived from the original on 6 August 2008. Retrieved 4 May 2008.
- 1 2 "VR History". victorianrailways.net. Archived from the original on 30 May 2008. Retrieved 4 May 2008.
- ↑ "circa 1905 Bradshaw's guide, page 24". Retrieved 25 April 2008.
- ↑ "1928 Country Passenger timetables". Retrieved 25 April 2008.
- ↑ "The Pride of the Diesel Fleet". The Victorian Railways Newsletter. July 1950. Retrieved 25 April 2008.
- ↑ "GEELONG FAST RAIL CONSTRUCTION ON TRACK" (Press release). Department of Premier and Cabinet, Victoria. 4 February 2004. Retrieved 4 May 2008.
The express travel time will be 45 minutes, a saving of at least six minutes over the existing express services.
- ↑ Public Record Office Victoria Series VPRS 12800/P1 Item H 1027 Archived 1 September 2007 at the Wayback Machine retrieved 2 October 2006
- ↑ "Victorian Railways, Museum Victoria, Australia: Spirit of Progress A2-class steam locomotive No. 995, 16 April 1962". prov.vic.gov.au. Retrieved 25 April 2008.
- ↑ "NEWPORT WORKSHOPS". The Argus. Melbourne. 4 January 1922. p. 14. Retrieved 3 January 2013 – via National Library of Australia.
- ↑ "HUGE WHEAT HAUL BY TRAIN". The Horsham Times. Vic. 6 June 1933. p. 4. Retrieved 3 January 2013 – via National Library of Australia.
- 1 2 3 4 5 6 7 8 Oberg, Leon (1984). Locomotives Of Australia 1850's - 1980's. NSW: Reed Books. p. 96. ISBN 0-7301-0005-7.
- 1 2 "AHRS Railway Museum: History 1900–1950". Australian Railway Historical Society. Archived from the original on 19 July 2008. Retrieved 2 October 2006.
- ↑ Pulverised Brown Coal Fuel for Steam Locomotives Buckland, John L. Australian Railway Historical Society Bulletin, July 1972 pp145-161
- ↑ "A2 locos". victorianrailways.net. Retrieved 14 June 2009.
- 1 2 3 4 Abbott, R.L. (November 1971). "Steam Locomotive Performance – the Modified Front End". ARHS Bulletin. Australian Railway Historical Society (409).
- ↑ Lee, Robert (2007). The Railways of Victoria 1854–2004. Melbourne University Publishing Ltd. p. 157. ISBN 978-0-522-85134-2.
- ↑ "100 defining aspects of Australian railways" (PDF). Australian Railway Historical Society. Archived from the original (PDF) on 16 July 2011. Retrieved 10 May 2008.
(H220) had... benefit of Brownbill's modified front-end experience
- ↑ Stevens, Colin (December 2000). Stack Talk. Steamrail Victoria. 11 (3): 10.
{{cite journal}}
: Missing or empty|title=
(help) - ↑ Carlisle, R M & Abbott, R L (1985). Hudson Power. ARHS. pp. 30–31. ISBN 0-85849-028-5.
- ↑ Pearce et al., p. 19
- ↑ "steamtrainartist.com Victorian Railways 'A2' CLASS 4-6-0". Archived from the original on 10 August 2004. Retrieved 2 October 2006.
- ↑ "Auditor General's Department EMA Disasters Database". Archived from the original on 26 September 2007. Retrieved 2 October 2006.
- ↑ Railpage discussion retrieved 2 October 2006
- ↑ "Australian Defence Department: On This Day – 8 May". Archived from the original on 3 September 2007. Retrieved 2 October 2006.
- 1 2 http://victorianrailways.net/motive%20power/a2steam/a2_cards_opt.pdf
- 1 2 3 4 5 6 Australian Railway History, August 2019, supplementary p.6. https://arhsnsw.com.au/wp-content/uploads/2019/07/ARH-982-August-2019-WEB-EXTRA.pdf
- ↑ "How rail crash happened". The Argus. 2 July 1947. Retrieved 26 January 2022.
- ↑ "VR A2 class - variations".
- ↑ "VR A2 class - variations".
- 1 2 3 4 5 ARHS Bulletin Supplement 1/58
- 1 2 3 4 5 6 7 8 9 10 "A2 Class history".
- ↑ Railway Museum (guide to exhibits). ARHS. 2008. p. 30.
External links
- Dee et al., Power Parade, VicRail Public Relations Division, Melbourne, 1981, ISBN 0-7241-3323-2
- Pearce et al., North Williamstown Railway Museum, ARHS, Melbourne, 1980, ISBN 0-85849-018-8
- The Recorder, ARHS, Adelaide, November 1985, ISSN 0158-1856
- AHRS Railway Museum History 1900–1950 retrieved on 6 September 2006
- National Library of Australia Photograph of prototype A2572, December 1907
- victorianrailways.net Stephenson A2936 hauling a goods train, 11 June 1930.
- victorianrailways.net Walschaerts A2973 leads a Stephenson A2on The Overland, circa 1930
- Public Record Office Victoria Classic VR photograph of A2-hauled passenger train with E type carriages crossing the Malmsbury Viaduct, 1945
- Public Record Office Victoria – A2856 is cut up for scrap.
- victorianrailways.net A2986, seen around 1962 near the end of its service life. Various modifications over the years have significantly altered its appearance from when photographed in 1916 (see top of this page)
- Steamrail A2986 page Photos detailing the progress of current restoration work on A2986
